Booting Debian with U-Boot

4 minute read

Several sources (e.g. IoT Developer Survey - slide 29, Samsung Artik - see firmware and Azure IoT Edge) indicate that Ubuntu/Debian based systems are a very popular choice for IoT gateways. On the other hand U-Boot is the de facto standard for booting embedded devices. This blog post will outline how you can elegantly combine those two popular choices.

boot

Having a proper boot loader setup for your IoT device is a mandatory prerequisite for reliable updates.

Requirements

I have been experimenting quite a lot with the Raspberry Pi boot loader and its Debian integration. The Raspberry Pi boot loader shines with its simpleness - which is perfect for its intended educational purpose.

However having a big IoT fleet in mind, I came to the conclusion that this setup can not fulfill all my requirements:

  • Boot standard Debian kernels without moving around files (such as ram disks, device tree binaries, kernel images).
  • “Atomically” switch from one kernel version to another one.
  • Support a multi boot scenario with a fail safe fallback.
  • Be configurable according to the use case.
  • Handle everything automatically during unattended updates.

The following explanations will show how I tweaked my Debian based Raspberry Pi image generation to support the above requirements.

Building the Image

Given you have installed the tool edi according to this instructions (please take a careful look at the “Setting up ssh Keys” section since you will need a proper ssh key setup in order to access the Rasperry Pi using ssh) and cloned the edi-pi project configuration repository from GitHub:

git clone https://github.com/lueschem/edi-pi.git
cd edi-pi

and installed a few extra tools:

sudo apt install e2fsprogs dosfstools bmap-tools

You are now ready to generate a minimal pure Debian stretch arm64 image for the Raspberry Pi 3:

Important Note
OS image generation operations require superuser privileges and therefore you can easily break your host operating system. Please ensure that you have a backup copy of your data.
sudo edi -v image create pi3-stretch-arm64.yml

The resulting image can be copied to an unmounted SD card (here /dev/mmcblk0) using the following command:

Important Note
Everything on the SD card will be erased!
sudo bmaptool copy artifacts/pi3-stretch-arm64.img /dev/mmcblk0

Once you have booted the Raspberry Pi 3 using this SD card you can access it using ssh (the access should be granted thanks to your ssh keys):

ssh pi@IP_ADDRESS

or via local login using keyboard and monitor (the password for the user pi is raspberry).

In the next section we will take a close look at the boot procedure of the image we have just generated.

Behind the Scenes

When you power on the Raspberry Pi the standard boot loader on the vfat partition (see /boot/firmware) will kick in. However, it will not directly load Linux but instead load the U-Boot boot loader also located on the vfat partition according to /boot/firmware/config.txt:

# Switch the CPU from ARMv7 into ARMv8 (aarch64) mode
arm_control=0x200

enable_uart=1

kernel=u-boot.bin

As soon as U-Boot has started we find ourselves in an environment that is familiar to most embedded Linux developers.

In the next step U-Boot will look for a file called boot.scr and boot the system accordingly. The instructions within boot.scr could look like this:

setenv bootargs console=tty0 console=ttyS1,115200 root=/dev/mmcblk0p2 rw elevator=deadline fsck.repair=yes net.ifnames=0 cma=128M rootwait

ext4load mmc 0:2 ${kernel_addr_r} /boot/vmlinuz-4.18.0-0.bpo.1-arm64
ext4load mmc 0:2 ${fdt_addr_r} /usr/lib/linux-image-4.18.0-0.bpo.1-arm64/${fdtfile}
ext4load mmc 0:2 ${ramdisk_addr_r} /boot/initrd.img-4.18.0-0.bpo.1-arm64

booti ${kernel_addr_r} ${ramdisk_addr_r}:${filesize} ${fdt_addr_r}

On the first line we configure the kernel’s command-line parameters. The second line will load the kernel image from the ext4 partition. The following two lines will load the matching device tree binary and the initial ram disk from the locations where the Debian package has placed them. Finally the booti (or bootz for armhf systems) command will boot into the loaded Debian system.

To bridge the gap between U-Boot and Debian I have developed a small package called edi-boot-shim. This package contains the small script edi-boot-shim (located in /usr/bin) that can be told to updated the boot instructions within boot.scr. By executing the following command, you will make sure that the given kernel package is getting used for the next boot:

sudo edi-boot-shim linux-image-4.18.0-0.bpo.1-arm64

In the case of an unattended update you might not want to call this command directly but rather rely upon a hook script that gets triggered during kernel updates. The edi-boot-shim package provides such a hook script (see /etc/kernel/postinst.d/zz-edi-boot-shim).

Finally a given use case might need some customized configuration. The behavior of the package edi-boot-shim can be fine tuned by adapting its configuration file /etc/edi-boot-shim/edi-boot-shim.cfg or by adjusting the boot command template (e.g. /etc/edi-boot-shim/boot.cmd.rpi.arm64).

Conclusion

Within the above setup the small Debian package edi-boot-shim bridges the gap between Debian and U-Boot. It should be pretty easy to adapt this shim package to any other board where you have a U-Boot bootloader and you would like to start Debian.

Now that we have a powerful boot loader setup it is time to figure out how we can provide highly reliable over the air updates with minimal down times and fallback scenarios.

As many people have figured out, a sudo apt update && sudo apt upgrade might not be reliable enough for managing a big IoT fleet.

Integrating one of the following approaches looks like a promising next step:

  • RAUC: Safe and secure software updates for embedded Linux
  • SWUpdate: Software Update for Embedded Systems
  • OSTree
